Applications
· Instrumentation and test equipment
· Audio
· Video
· Office equipment
· Material handling equipment
· Building and home automation
· Industrial controls
· Robotics
Specifications
· Current Rating: 1A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 300V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8”) Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Could solve critical size requirement problem.
● Easy assembling and low production cost
● Simple and clean internal design
● Simplify manufacturing procedure
Advantages
● Complete product range, full pitch series
● Good materials, all materials meet RoHS, REACH certification
● Both small and large orders are acceptable
● Fast delivery time of average 4 weeks
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in soldering female header pins connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in soldering female header pins connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
What is the soldering temperature for CNT's connectors?
PBT soldering temperature resistance is 230℃, PA6T 260℃ and LCP 280℃.
How much dielectric withstanding voltage is for CNT's connectors?
The circular and DIN connectors withstand 1000 V (AC) at 50 or 60 Hz for 60 seconds with no flashover or breakdown between every two contacts or between every contact and outer contour of the housing.
What material are CNT's connectors made of?
CNT's connectors are made of PBT, Nylon and LCP, you could find the details in our drawing.
