Applications
· Security equipment
· Monitor
· Office equipment
· Home appliances
· IoT
· Industrial controls
· Robotics
Specifications
· Current Rating: 1A Max
· Insulation Resistance: 500MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -25°C - +85°C
Materials
· Plating: Tin--Standard
· Contact Material: Copper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
- Light weight and flexible.
- Compachness of electronic products
- Easy assembling and low production cost
- Simple and clean internal design
Advantages
- Skilled and stable staff
- Good before-sales and after-sales service
- Well package, protect products during long international transit
- Mechanized production, stable quality
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in circuit board connections with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in circuit board connections , welcome you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
What is the insulation resistance for CNT's connectors?
It's upon to different pitch, please check the drawing to get the specific informaiton.
What is the soldering temperature for CNT's connectors?
PBT soldering temperature resistance is 230℃, PA6T 260℃ and LCP 280℃.
How much dielectric withstanding voltage is for CNT's connectors?
The circular and DIN connectors withstand 1000 V (AC) at 50 or 60 Hz for 60 seconds with no flashover or breakdown between every two contacts or between every contact and outer contour of the housing.
