Applications
· Stereo Amplifier
· Audio
· Video
· Scanner
· IoT
· Security equipment
· Power systems
· Communication networks
Specifications
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8”) Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Reduced electromagnetic emissions
● Improved environmental protection
● Enhanced system protection
● Make it possible to connect devices from different manufacturers, increasing compatibility and flexibility.
Advantages
● Good before-sales and after-sales service
● Well package, protect products during long international transit
● Mechanized production, stable quality
● Complete product range, full pitch series
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in surface mount female header connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in surface mount female header connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
How do you ensure the electrical stability of connectors over time?
1)Select high-quality connectors
2)Conduct proper testing: Electrical stability can be affected by environmental conditions such as temperature, humidity, and dust.
3)Monitor the environmental conditions: Electrical stability can be affected by environmental conditions such as temperature, humidity, and dust. The factory should ensure that the connectors are installed in a suitable environment that does not expose them to extreme temperature or humidity.
4)Maintain cleanliness: Dirt, dust, and other contaminants can interfere with the electrical connectivity of connectors.
What are the different options for high-speed data transmission with board-to-board connectors?
There are several different options for high-speed data transmission with board-to-board connectors. Here are a few examples:
Differential Pair Connectors: Differential pair connectors are designed to provide high-speed data transmission by transmitting data through two wires with opposite polarity. They can achieve high data rates and are commonly used in high-speed applications.
Coaxial Connectors: Coaxial connectors are designed to transmit high-frequency signals with low attenuation and interference. They are commonly used in high-speed data applications where low noise and high data rates are critical.
Optical Connectors: Optical connectors use light to transmit data and are ideal for applications that require high-speed data transmission over long distances. They can achieve data rates in the range of 10 Gbps and above.
Micro Coaxial Connectors: Micro coaxial connectors are miniature versions of coaxial connectors and are used in high-speed applications where space is limited. They can achieve high data rates while maintaining a small footprint.
Edge Connectors: Edge connectors are designed to provide high-speed data transmission between two PCBs. They are commonly used in high-speed applications and can achieve data rates in the range of 10 Gbps and above.
Stacked Connectors: Stacked connectors are designed to provide high-speed data transmission between multiple PCBs in a vertical orientation. They can achieve high data rates while minimizing the space required for interconnects.
