Applications

· Power systems

· IoT

· Home appliances

· Servo drives

· Security equipment

· Monitor

· LED Screen

Specifications

· Current Rating: 3A Max

· Insulation Resistance: 1000MΩ Min

· Dielectric Withstanding: 600V AC

· Contact Resistance: 20mΩ Max

· Operating Temperature: -40°C - +105°C

· Solderability: Reflow capable up to 260°C

Materials

· Plating: Gold flash(0.8”) Standard

Higher gold available

Tin

· Contact Material: Cooper Alloy

· Housing Material: High-temperature Thermoplastic

· Environmental: UL94 V0

Others

· 2D drawing

· Contact CNT to get 3D file

· RoHS & REACH compliant

· UL compliant

product-1098-776

product-1104-773

Features

● Help to make smaller finished product come true
● Simplify the assembly process of electronic products
● More convenient to replace and upgrade connectors
● Easy to replace old connectors, save more time and labor cost.

Advantages

● Well package, protect products during long international transit
● Mechanized production, stable quality
● Complete product range, full pitch series
● Good materials, all materials meet RoHS, REACH certification

Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in Interconnects Rectangular Connectors Board Spacers connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in Interconnects Rectangular Connectors Board Spacers connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
