Applications
· Smart Meters & Terminals
· Video
· Monitor
· Frequency Converter
· Medical equipment
· Servo drives
· LED Screen
Specifications
· Current Rating: 5A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 1500V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -25°C - +85°C
Materials
· Plating: Tin--Standard
· Contact Material: Copper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
- Compachness of electronic products
- Easy assembling and low production cost
- Simple and clean internal design
- Simplify manufacturing procedure
Advantages
- Mechanized production, stable quality
- Complete product range, full pitch series
- Good materials, all materials meet RoHS, REACH certification
- Both small and large orders are acceptable
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in cable to board connector with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in cable to board connector, welcome you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
What materials are used in your products?
Most of the products are made of PA6T plastic, and a few of them are made of PBT. Some also use LCP, see the corresponding drawings for details.
What is the soldering temperature resistance of the product?
PBT soldering temperature resistance is 230℃, PA6T 260℃ and LCP 280℃
How long is the product warranty time?
Gold plating for 1 year, tin plating for half a year.
