Applications
· Industrial automation
· Medical equipment
· Office equipment
· Audio
· Video
· Scanner
Specifications
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8”) Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Meet the demands of miniaturizing electronic products
● Could solve critical size requirement problem.
● Low cost multiple pitches connectors per your application requirements.
● Light weight and flexible.
● Compachness of electronic products
Advantages
● Various transporation method
● According to the market demand, the product is continuously developed
● Customized products avaiable
● Low cost and high reliability
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in pin header male female connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. And demand in pin header male female connectors, welcome all of you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
What are the storage requirements?
Temperature: 5℃-30℃ and Humidity: ≤65%
How do you improve your supply chain management?CNT improve the supply chain management by implementing just-in-time (JIT) delivery systems, manage inventory, and developing strong relationships with suppliers and 2nd source plan.
How much dielectric withstanding voltage is for CNT's connectors?
The circular and DIN connectors withstand 1000 V (AC) at 50 or 60 Hz for 60 seconds with no flashover or breakdown between every two contacts or between every contact and outer contour of the housing.
How to buy your products?
Please contact our company's sales staff directly to confirm the demand and make a purchase. We'll happily look after all your requirements.
