Applications
· Communication networks
· Elevators
· Industrial controls
· Robotics
· Instrumentation and test equipment
Specifications
· Current Rating: 0.8A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 30mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Tin
Gold flash(0.8”) Standard
Higher gold available
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Low cost multiple pitches connectors per your application requirements.
● Light weight and flexible.
● Compachness of electronic products
● Easy assembling and low production cost
● Simple and clean internal design
Advantages
● Free sample
● Perfect quality control from materials to finished products.
● Traceability of Order and raw material
● Systematic lab testing ability
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in dupont pin header headers connector with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in dupont pin header connector, welcome you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
What certifications does the product have?
ROHS, REACH, UL, MSDS, HF
What products do you produce?
Products include board-to-board connectors of pin headers, female headers, box header; board-to-wire connectors of wafer, FPC, RJ, and various customized wiring harnesses.
What is the insulation resistance for CNT's connectors?
It's upon to different pitch, please check the drawing to get the specific informaiton.
