Applications
· Audio
· Cordless Phone
· Scanner
· Notebook
· Cell Phone
· Security equipment
· Home Appliance
Specifications
· Current Rating: 1A Max
· Insulation Resistance: 500MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 30mΩ Max
· Operating Temperature: -25°C - +85°C
Materials
· Plating: Tin--Standard
Gold flash option
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
Reduce welding and wiring time, save installation space.
Provides reliable connections and reduces the likelihood of connection failures.
Reliable connectivity.
Safe and reliable.
Advantages
Systematic lab testing ability
Good before-sales and after-sales service
Good materials, all materials meet RoHS, REACH certification
Both small and large orders are acceptable
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
How do you improve the competitiveness in the global market?
CNT insists on focusing on product quality, reducing costs, providing good before and after sale service to improve the competitiveness.
What is the pitch of a board-to-wire connector?
The pitch of a board-to-wire connector refers to the distance between the centers of adjacent pins or contacts on the connector. This distance is usually measured in millimeters or inches. The pitch of a board-to-wire connector is an important specification that must be considered when selecting a connector because it determines the spacing and size of the wires that can be connected to it.Common pitches for board-to-wire connectors include 2.54 mm (0.1 inches), 3.96 mm (0.156 inches), and 5.08 mm (0.2 inches).
What is the mating cycle of board-to-wire connectors?
The mating cycle of board-to-wire connectors varies depending on the connector type and manufacturer. Typically, the mating cycle ranges from 10 to 100 cycles.
Can you provide technical support for your products?
1)Online resources: We have some product knowledge on our website.
2)Customer service hotline: You could call our sales to get technical support at any time.
3)Email support: You could send email to to get technical support at any time.
4)Video Support: Because of the high cost of international trip, so we couldn't provide on-site support, but we could support by video commuincation.
