Applications
· Audio
· Video
· Scanner
· Cordless Phone
· Fax
· Notebook
· Personal Computer
Specifications
· Current Rating: 0.3A Max
· Insulation Resistance: 50MΩ Min
· Dielectric Withstanding: 250V AC
· Contact Resistance: 30mΩ Max
· Operating Temperature: -25°C - +85°C
Materials
· Plating: Gold flash--Standard
Tin option
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
- Help to make smaller finished product come ture
- Simplify the assembly process of electronic products
- High performance contact design
- High reliable board interconnecting
Advantages
- Free sample
- Perfect quality control from materials to finished products.
- Low cost and high reliability
- Integrated production and assembly pocess can save your time to market and increase your profit.
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in fpc 0.3 mm connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in fpc 0.3 mm connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
What is the insulation resistance for CNT's connectors?
It's upon to different pitch, please check the drawing to get the specific informaiton.
What is the soldering temperature for CNT's connectors?
PBT soldering temperature resistance is 230℃, PA6T 260℃ and LCP 280℃.
How much dielectric withstanding voltage is for CNT's connectors?
The circular and DIN connectors withstand 1000 V (AC) at 50 or 60 Hz for 60 seconds with no flashover or breakdown between every two contacts or between every contact and outer contour of the housing.
