Applications
· Instrumentation and test equipment
· Industrial automation
· Office equipment
· Home appliances
· Servo drives
· Robotics
· LED Screen
· Audio
Specifications
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8”) Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Help to make smaller finished product come true
● Simplify the assembly process of electronic products
● More convenient to replace and upgrade connectors
● Easy to replace old connectors, save more time and labor cost.
Advantages
● Systematic lab testing ability
● Mature R&D team
● Skilled and stable staff
● Good before-sales and after-sales service
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in female connector wire connectors electrical connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in female connector wire connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
What are the forms of CAP for SMT products?
The default tape and reel packaging comes with a cap. And there are the following types of caps: mylar, plastic cap and metal cap. Some customers do not need a cap and need to be notified in advance.
What does your quality inspection process include?
Incoming material inspection, first article inspection, process inspection, finished product inspection, and outgoing inspection.
What products do you produce?
Products include board-to-board connectors of pin headers, female headers, box header; board-to-wire connectors of wafer, FPC, RJ, and various customized wiring harnesses.
