Applications
· Servo drives
· Material handling equipment
· IoT
· Security equipment
· Monitor
· Instrumentation and test equipment
· Audio
· Video
Specifications
· Current Rating: 0.5A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 300V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8”) Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact CNT to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Low cost multiple pitches connectors per your application requirements.
● Light weight and flexible.
● Simplify manufacturing procedure
● High reliable board interconnecting
Advantages
● Mechanized production, stable quality
● Complete product range, full pitch series
● Fast delivery time of average 4 weeks
● Professional consultancy & technical support
Kunshan Connector Electronics Ltd.(CNT) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. CNT is a reliable manufacturer in 40 pin female header connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in 40 pin female header connectors, welcome all of you to contact us. Just call or send email to us to get professional support, believe that CNT will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
What are the forms of CAP for SMT products?
The default tape and reel packaging comes with a cap. And there are the following types of caps: mylar, plastic cap and metal cap. Some customers do not need a cap and need to be notified in advance.
What products do you produce?
Products include board-to-board connectors of pin headers, female headers, box header; board-to-wire connectors of wafer, FPC, RJ, and various customized wiring harnesses.
How long is the sample lead time?
Generally samples need 3 days to 2 weeks, it depends on the materials stock.
